1. Overview

The ZMB Gate Pump is designed for applications such as flood prevention and drainage, water diversion and drainage, and irrigation water distribution, including urban rainwater pump stations, flood control pump stations, agricultural irrigation pump stations, and drainage pump stations.

This pump excels in low-head, high-flow scenarios. Under identical head and specific speed conditions, it demonstrates higher overall efficiency compared to conventional vertical axial flow pumps and submerged vertical axial flow pumps. Specifically, the lower the head and the higher the specific speed, the greater the efficiency improvement.

It is suitable for conveying water or other liquids with physical and chemical properties similar to water, with a maximum liquid temperature of 40°C (104°F).

2. Application

● Flood Prevention and Drainage Systems

● Water Diversion and Distribution Projects

● Irrigation Water Supply Networks

● Urban Stormwater Pump Stations

● Flood Control Pump Stations

● Agricultural Irrigation Pump Stations

● General Drainage Infrastructure

3. Characteristics

● Compact structure with shortened axial dimensions, lightweight, and minimal metal consumption.

● Operates submerged, producing low noise and vibration, effectively reducing acoustic and thermal pollution.

● Short flow path with straight channel, minimizing head loss and achieving high system efficiency.

● Symmetrical design for flexible bidirectional installation, enabling reverse flow operation.

● Lightweight and compact, allowing quick self-coupling installation.

● Simplified pump station structure, reducing engineering workload, cost, and construction duration.

● Easy operation and maintenance, supporting automated control.

•

  Zmb Gate Pump

  Download

• What are the main advantages of the ZMB Gate Pump?

  • Key advantages include compact design, easy installation, low noise, high efficiency, reduced construction costs, and the ability to perform both pumping and gate functions.

• What makes the ZMB Gate Pump energy-efficient?

  • The pump features a short and straight flow path, which minimizes energy loss and improves overall efficiency. Its symmetrical design also allows for bidirectional pumping, further enhancing versatility.

• Can the ZMB Gate Pump handle large water volumes?

  • Yes, the pump is designed for high-flow applications, making it ideal for flood control and large-scale drainage projects.

• Can the ZMB Gate Pump be installed in different orientations?

  • Yes, the pump’s symmetrical design allows for flexible installation, including bidirectional pumping configurations.
